Fixed hydraulic scissor lifting platform
Classification :
Keywords : Convet Elevator Group
fixed hydraulic scissor lifting platform
Introduction to fixed hydraulic shear lifting platform
fixed hydraulic shear lifting platform is a special hydraulic lift used for transporting goods between building floors. Its main functions include transporting goods between various working floors, lifting cars between floors of three-dimensional garage and underground garage.
Working principle:
The working principle of the fixed hydraulic shear lifting platform is based on the hydraulic system. The motor drives the oil pump to extract the hydraulic oil from the oil tank and transfer it to the hydraulic cylinder through the hydraulic pipeline. The pressure of hydraulic oil makes the hydraulic cylinder piston move up or down, so as to push the lifting platform or carriage up and down.
Structural characteristics:
safety protection device : the platform hydraulic system is set with anti-fall and overload safety protection device to ensure the safety;
multi-point control : each floor and lifting platform work surface can be set operation buttons to achieve multi-point control;
strong structure : The product has strong structure, large carrying capacity, stable lifting, simple installation and maintenance;
Applicable environment : suitable for low floor cargo transportation, is an economical and practical alternative to the elevator ideal equipment.
Application scenario:
Fixed hydraulic shear lifting platform is widely used in the following scenarios:
inter-storey cargo transport : used for transporting goods between different floors to improve work efficiency
three-dimensional garage and underground garage : used for car lifting, convenient vehicle access
industrial field : widely used in vehicle maintenance, kiln, chemical plant and other places, because of its large carrying capacity, simple operation and favored.
Cargo Lift introduction
Cargo lift is a kind of lifting equipment used for cargo transport, mainly used to solve the problem of cargo transport in the vertical direction, widely used in commercial, warehousing, logistics and other industries.
The design features and use scenarios of the freight elevator are as follows:
| Model | Loading Capacity | Lifting height | Min.height | Table size | Power |
| SJD0.5-4.5 | 500kg | 4500mm | 150mm | 2000*1500mm | 2.2kw |
| SJD1.0-4.5 | 1000kg | 4500mm | 150mm | 2000*1500mm | 3kw |
| SJD2.0-4.5 | 2000kg | 4500mm | 150mm | 2000*1500mm | 3kw |
| SJD3.0-4.5 | 3000kg | 4500mm | 160mm | 2000*1500mm | 3kw |
| SJD0.5-7.5 | 500kg | 7500mm | 150mm | 1200*1200mm | 1.5kw |
| SJD1.0-7.5 | 1000kg | 7500mm | 150mm | 1800*1400mm | 2.2kw |
| SJD2.0-7.5 | 2000kg | 7500mm | 150mm | 2000*1500mm | 2.2kw |
| SJD3.0-7.5 | 3000kg | 7500mm | 160mm | 2000*1600mm | 3kw |
| SJD1.0-10.5 | 1000kg | 10500mm | 150mm | 1800*1400mm | 2.2kw |
Design feature
cargo elevator:This is a standard freight elevator, mainly used for the transport of goods, usually accompanied by people. The car of the cargo elevator is long and narrow and runs between at least two vertical rigid guides. The performance of the cargo elevator is good and the price is affordable
hydraulic lift elevator: combined with the advantages of cargo elevator and electric hoist freight elevator, cost-effective, can meet the requirements of performance and safety, but also to adapt to the needs of low budget. The hydraulic lift cargo elevator can be customized according to the site space and needs of the size, the price according to the height, load and platform size varies .
Usage scenario
commercial:Used for shopping malls, office buildings of goods transportation.
storage:Used for efficient vertical transport of goods in warehouses.
logistics:Used in logistics centers for fast and efficient handling of goods.
construction:Used for vertical transport of materials and equipment on construction sites.
maintenance
As a precise means of transport, scientific maintenance can greatly extend its service life. Regular inspection, cleaning, lubrication and adjustment are the key to maintaining the normal operation of the freight elevator. In addition, reasonable use and safety management are also important aspects to ensure the safe operation of the cargo elevator .
